• Plastic housing
• Up to Max. 1920×1080 resolution
• S+265/H.265/H.264B/H.264M/H.264H
• Color:0.02Lux@(F2.0,AGC ON),B/W:0Lux with IR
• Smart IR, IR range 30m
• Support smart surveillance
• Operating conditions -30℃~60℃, humidity 95% or less (no condensation)
• POE 802.3af,Max. 3W
|
Camera |
|
|
Image Sensor |
1/3"CMOS |
|
Min. Illumination |
Color:0.02Lux@(F2.0,AGC ON),B/W:0Lux with IR |
|
Shutter Time |
1s~1/100000s |
|
Day&Night |
IR-cut filter with auto switch (ICR) |
|
WDR |
DWDR |
|
S/N |
>47.8dB |
|
Angle Adjustment |
0~340°(P); 0~75°(T); 0~360°(R) |
|
Lens |
|
|
Lens Type |
Fixed focal lens |
|
Focal Length |
2.8mm |
|
Lens Mount |
M12 |
|
Aperture Range |
F2.0 |
|
Field of View |
94.4°(H); 53.2°(V); 108.2°(D) |
|
DORI Distance |
Detect:41.48m Observe:16.46m Recognize:8.3m Identify:4.1m |
|
Illuminator |
|
|
IR LEDs |
1 |
|
IR Distance |
30m |
|
Wavelength |
850nm |
|
Compression Standard |
|
|
Video Compression |
S+265/H.265/H.264B/H.264M/H.264H |
|
Video Bit Rate |
32k~4Mbps |
|
Audio Compression |
G.711A/G.711U |
|
Audio Sampling Rate |
8kHz |
|
Image |
|
|
Max. Resolution |
1920×1080@30fps |
|
Main Stream |
PAL:25fps(1920×1080, 1280×720, 704×576, 640×480) NTSC:30fps(1920×1080, 1280×720, 704×480, 640×480) |
|
Sub Stream |
PAL:25fps(704×576, 704×288, 352×288, 640×360) NTSC:30fps(704×480, 704×240, 352×240, 640×360) |
|
BLC |
Yes |
|
HLC |
Yes |
|
AGC |
Yes |
|
3D DNR |
Yes |
|
White Balance |
Auto/Semi-Auto/Manual/Sunshine/Nature Light/Warmlight Lamp/Daylight Lamp/Filament Lamp/Lock White Balance |
|
OSD |
Overlay of additional characters in 1 regions, 1 line, with a maximum of 48 characters or 16 Chinese characters per region; 16*16/32*32/48*48 |
|
Privacy Mask |
4 black static areas |
|
Defog |
Yes |
|
Feature |
|
|
Alarm Trigger |
Motion Detection; IP Address Conflict |
|
Interface |
|
|
Communication Interface |
1*RJ-45,10/100 Mbps self-adaptive Ethernet port |
|
General |
|
|
Web Client Language |
English |
|
Operating Temperature |
-30℃~60℃ |
|
Operating Humidity |
Humidity 95% or less (no condensation) |
|
Storage Temperature |
-30℃~60℃ |
|
Storage Humidity |
Humidity 95% or less (no condensation) |
|
Power Supply |
POE 802.3af,MAX 3W |
|
Protection |
Surge4000V; ESD6000V |
|
Boundary Dimensions |
95(L)95(W)67(H)mm |
|
Package Dimensions |
105(L)105(W)85(H)mm |
|
GrossWeight |
0.17kg |
