·Up to 5MP,3072×1728@30fps
·Color:0.0001lux@ (F1.6,AGC ON),B/W:0lux with IR
·S+265/H.265/H.264B/H.264M/H.264H/Motion JPEG
·Optical zoom 44X
·IR range up to 200m
·Support microSD/microSDHC/microSDXC card,up to 512GB
·Support smart surveillance, detect up to 32 faces at the same scene
·Support human/vehicle classification
·Operating conditions -40℃~70℃(-40℉~158℉), ≤95%RH
·AC24V±25%\DC24V±10%, PoE:IEEE 802.3bt IP66
|
Camera |
|
|
Image Sensor |
1/1.8"CMOS |
|
Min. Illumination |
Color:0.0001lux@ (F1.6,AGC ON),B/W:0lux with IR |
|
Shutter Time |
1s~1/100000s |
|
Day&Night |
IR-cut filter with auto switch (ICR) |
|
Smart IR |
Yes |
|
WDR |
120dB |
|
S/N |
40.6dB |
|
Lens |
|
|
Focal Length |
6mm～264mm |
|
Optical Zoom |
44X |
|
Digital Zoom |
16X |
|
Zoom Speed |
<5s |
|
Aperture Range |
F1.6~F5.3 |
|
Aperture Type |
Auto(P-Iris) |
|
Field of View |
59.2~2.5°(H); 34.6°~1.4°(V); 66.7~2.9°(D) |
|
Focus Control |
Auto/Semi-auto/Manual |
|
Close Focus Distance |
100mm~1000mm |
|
DORI Distance |
Detect:2414m Observe:958m Recognize:483m Identify:241m |
|
Pan&Tilt |
|
|
Pan Range |
0~360°(P) |
|
Pan Speed |
Manual Speed:0.1°～180°/s Preset Speed:240°/s |
|
Tilt Range |
-16°~90°(T) (Default -3°~90°(T)) |
|
Tilt Speed |
Manual Speed:0.1°～120°/s Preset:180°/s |
|
3D Position |
Yes |
|
Preset |
500 |
|
Cruise |
16(up to 32 presets per cruise) |
|
Scan |
8 |
|
Pattern |
8,each with 600s memory or 1000 orders |
|
Scheduled Task |
Preset,Cruise,Scan,Pattern |
|
North Point |
Yes(Manual setting) |
|
Power-off Memory |
Yes |
|
Preset Freezing |
Yes |
|
Illuminator |
|
|
IR LEDs |
10 |
|
IR Distance |
Up to 200m |
|
Wavelength |
850nm |
|
IR Irradiation Angle |
Yes |
|
White LEDs |
4 |
|
Whitelight Distance |
50m |
|
Compression Standard |
|
|
Video Compression |
S+265/H.265/H.264B/H.264M/H.264H/Motion JPEG |
|
Video Bit Rate |
32Kbps~16Mbps |
|
Audio Compression |
G.711A/G.711U/ADPCM_D/AAC_LC |
|
Audio Sampling Rate |
8KHz/32KHz/48KHz |
|
Image |
|
|
Max. Resolution |
5MP,3072×1728@30fps |
|
Main Stream |
PAL:25fps(3072×1728,2688×1520,2560×1440,2304×1296,1920×1080,1280×960,1280×720),50fps（1920×1080,1280×960,1280×720) NTSC:30fps(3072×1728,2688×1520,2560×1440,2304×1296,1920×1080,1280×960,1280×720),60fps(1920×1080,1280×960,1280×720) |
|
Sub Stream |
PAL:25fps(704×576,704×288,640×360,352×288) NTSC:30fps(704×480,704×240,640×360,352×240) |
|
Third Stream |
PAL:25fps(1920×1080,1280×720,704×576,640×360,704×288,352×288) NTSC:30fps(1920×1080,1280×720,704×480,640×360,704×240,352×240) |
|
BLC |
Yes |
|
HLC |
Yes |
|
AGC |
Yes |
|
3DNR |
Yes |
|
White Balance |
Auto/Semi-Auto/Manual/Sunshine/Nature Light/Warmlight Lamp/Daylight Lamp/Filament Lamp/Lock White Balance |
|
ROI |
7 rectangular 3D fixed focus areas,supporting 1 rectangular dynamic tracking ROI |
|
EIS |
Yes |
|
OSD |
5 regions(Each region can have a maximum of 127 characters,up to 5 lines); 16*16/24*24/32*32/48*48/64*64/96*96/adaptable size; Vector/Lattice |
|
Defog |
Yes |
|
Flip |
Normal/Horizontal Mirror/Vertical Mirror/Inverted Flip |
|
Regional Exposure |
Yes |
|
Regional Focus |
Yes |
|
Demist |
Yes |
|
Privacy Mask |
24 regions(Up to 4 blocks in the same scene) |
|
Feature |
|
|
General Alarm |
Motion Detection; Mask Alarm; Alarm Input |
|
Exceptions Alarm |
Disk Full; Disk R/W Error; Recording Exception; IP Address Conflict; MAC Address Conflict; FTP Server Exception ; Network cable disconnected |
|
Linkage Method |
Send Email; Trigger Sound; Trigger Warmlight; Trigger Recording; Trigger Capture; Notify Surveillance Center; Alarm Output |
|
Video Analytics |
Human/Vehicle Classification; Tripwire; Double Tripwire; Perimeter; Object Abandon; Object Missing; Heatmap; Loitering; Running; Parking; People Counting; Safety Helmet Detection; On Duty Detection; Video Abnormal; Audio Abnormal; Crowed Detection |
|
Auto Early Warning(AEW) |
Yes |
|
Auto-Tracking |
Yes |
|
Face Mode |
Face Capture |
|
Face Capture Performance |
Best Face Size 60 Pixels; Minimum face size 19 Pixels; Best facial capture distance ≤100m; Detect up to 32 faces at the same scene; Capture up to 16 faces at the same scene; Capture rate ≥99%(continuous scene with 10 people or less); Gender 85%,age (±5) 85%,mask 90%,glasses 85%,beard 80% (Less than 10 people in view) |
|
Network |
|
|
ANR |
Yes |
|
Protocols |
HTTP; HTTPS; UDP; UPnP; ICMP; IGMP; SNMP v1\v2\v3; DHCP; DNS; DDNS; Easy DDNS; NTP; SMTP; TLS v1.2; SSL; 802.1x; QoS; IPv4; IPv6; PPPoE; SSH; Unicast; Multicast; ARP; RTP; SRTP; FTP; SFTP; RTSP; TCP; SMB; CIFS |
|
System Compatibility |
P2P; ONVIF(Profile S/T/G/M); SDK; CGI; Milestone; RTSP; RTMP; RTMP; HTTP PUSH |
|
Remote Connection |
≤7 |
|
User/Host |
32users, Level 4:Admin/Browse/Browse+Control/Browse+Control+Set |
|
Client |
Easy7 VMS |
|
Moblie Client |
EasyLive Plus |
|
Web |
IE10+; Firefox52+; Edge89+; Safari11+; Chrome57+ |
|
Interface |
|
|
Communication Interface |
1×RJ45 (10/100Base-T) |
|
Audio I/O |
1×input, two-core , max. input amplitude:3.3 Vpp, input impedance:1 KΩ, interface type:non-equilibrium; 1×output, two-core, max. output amplitude:3.3 Vpp, output impedance:100 Ω, interface type: non-equilibrium |
|
Alarm I/O |
8×input,TTL,3mA,3.3VDC; 2×relay output,1A,24VDC |
|
Built-in Speaker |
1×Built-in Loudspeaker, 4Ω4W |
|
Reset Button |
Yes |
|
On-board Storage |
Support microSD/microSDHC/microSDXC card,up to 512GB |
|
Additional Interfaces |
RS-485 |
|
Wiper |
Yes |
|
General |
|
|
Web Client Language |
19 languages Simple Chinese/English/Traditional Chinese/Spanish/Italian/Korean/Turkish/Russian/Thai/Polish/French/Dutch/Hebraism/Vietnamese/Arabic/German/Ukrainian /Portuguese/Albanian |
|
Operating Temperature |
-40℃~70℃(-40℉~158℉) |
|
Operating Humidity |
≤95%RH |
|
Storage Temperature |
-40℃~70℃(-40℉~158℉) |
|
Storage Humidity |
10%~95%RH(non-condensing) |
|
Power Supply |
AC24V±25%\DC24V±10%; PoE:IEEE 802.3bt |
|
Power Consumption |
13.4W; 45W |
|
Protection |
Surge4000V; ESD6000V; IP66 |
|
Material |
Metal |
|
Boundary Dimensions |
222(D)372(H)mm |
|
Package Dimensions |
320(L)320(W)520(H)mm |
|
GrossWeight |
8.95kg |
|
NetWeight |
5.3Kg |
