·Dual PTZ design
·5MP varifocal PTZ-bullet for overall scenario and 5MP speed dome for detailed view
·Resolution up to 3072×1728@20fps
·Min. illumination Color: 0.0008Lux@F1.0 (PTZ-bullet)
·Optical zoom of PTZ-bullet: 4×, digital zoom 16×
·Optical zoom of speed dome: 6×, digital zoom 16×
·Smart IR, IR Range: 100m
·Support blue&red flash warning
·Bulit-in dual Mic& dual Speaker
·Built-in Electronic Compass
·Support video structure analysis
·S+265/H.265/H.264/M-JPEG
·Support Human/Vehicle Classification
·Plugin Free
·P66
|
Camera |
|
|
Image Sensor |
Panorama:1/1.8"CMOS Detail:1/1.8"CMOS |
|
Min. Illumination |
Panorama:0.0008lux Detail:0.003lux |
|
Shutter Time |
1s~1/100000s |
|
Day&Night |
IR-cut filter with auto switch (ICR) |
|
WDR |
120dB |
|
Lens |
|
|
Focal Length |
Panorama:2.8mm～12mm Detail:9mm～54mm |
|
Optical Zoom |
Panorama:4X Detail:6X |
|
Digital Zoom |
Panorama:N/A Detail:16X |
|
Zoom Speed |
<3s |
|
Aperture Range |
Panorama:F1.36 Detail:F1.35~F1.55 |
|
Field of View |
Panorama:114.20°～47.94°(H) Detail:41°～9.1°(H); Panorama:59.36°～27.07°(V) Detail:23.4°～5.2°(V); Panorama:141.10°～55.09°(D) Detail:46.7°～10.4°(D) |
|
Focus Control |
Panorama: N/A Detail:Auto/Semi-auto/Manual |
|
Iris Control |
Panorama:Fixed Detail:Auto |
|
Close Focus Distance |
Panorama:1000mm~2500mm Detail:500mm~3000mm |
|
DORI Distance |
Panorama: Detect:124m Observe:49m Recognize:25m Identify:12m Detail: Detect:626m Observe:248m Recognize:125m Identify:62m |
|
Pan&Tilt |
|
|
Pan Range |
Panorama:-130~130° Detail:0~360° |
|
Tilt Range |
Panorama:0°-30° Detail:'-16°～90° (Default -3°～90°) |
|
Tilt Speed |
Panorama: Manual Speed:15°/s Preset Speed:15°/s Detail: Manual Speed:100°/s Preset Speed:150°/s |
|
3D Position |
Yes |
|
Preset |
500 |
|
Cruise |
16, up to 32 presets per cruise |
|
Scan |
8 |
|
Pattern |
8, each with 600s memory or 1000 orders |
|
Scheduled Task |
Preset、Cruise、Scan、Pattern |
|
North Point |
Yes |
|
Power-off Memory |
Yes |
|
Preset Freezing |
Yes |
|
Illuminator |
|
|
IR LEDs |
Panorama: N/A Detail:6 |
|
IR Distance |
Panorama: N/A Detail:100m |
|
Wavelength |
850nm |
|
IR Irradiation Angle |
Panorama:N/A Detail:Adjustable by Zoom |
|
White LEDs |
Panorama:4 Detail:N/A |
|
Whitelight Distance |
Panorama:30m Detail:N/A |
|
Red and blue alarm flash |
Yes |
|
Laser |
Panorama:N/A Detail:N/A |
|
Laser Distance |
Panorama:N/A Detail:N/A |
|
Compression Standard |
|
|
Video Compression |
S+265/H.265/H.264/M-JPEG |
|
Video Bit Rate |
Panorama:32Kbps~16Mbps Detail:32Kbps~16Mbps |
|
Audio Compression |
G.711A/G.711U/ADPCM_D/AAC_LC |
|
Audio Sampling Rate |
8KHz/32KHz/48KHz |
|
Image |
|
|
Max. Resolution |
Panorama:2560×1440@25fps Detail:2560×1440@25fps |
|
Main Stream |
Panorama: PAL:20fps(3072*1728), 25fps(2560×1440, 2304×1296, 1920×1080, 1280×720, 640×480, 704×576) NTSC:20fps(3072*1728), 30fps(2560×1440, 2304×1296, 1920×1080, 1280×720, 640×480, 704×480) Detail: PAL:20fps(3072*1728), 25fps(2560×1440, 2304×1296, 1920×1080, 1280×720, 640×480, 704×576) NTSC:20fps(3072*1728), 30fps(2560×1440, 2304×1296, 1920×1080, 1280×720, 640×480, 704×480) |
|
Sub Stream |
Panorama: PAL:25fps(704×576, 640×360, 704×288, 352×288) NTSC:30fps(704×480, 640×360, 704×240, 352×240) Detail: PAL:25fps(704×576, 640×360, 704×288, 352×288) NTSC:30fps(704×480, 640×360, 704×240, 352×240) |
|
Third Stream |
Panorama: PAL:25fps(704×576, 704×288, 352×288) NTSC:30fps(704×480, 704×240, 352×240) Detail: PAL:25fps(704×576, 704×288, 352×288) NTSC:30fps(704×480, 704×240, 352×240) |
|
BLC |
Yes |
|
HLC |
Yes |
|
AGC |
Yes |
|
White Balance |
Yes |
|
ROI |
7 Dynamic Areas for Both Main and Sub Stream |
|
EIS |
Panorama:Yes Detail:Yes |
|
OSD |
5 regions(Each region can have a maximum of 127 characters,up to 5 lines); 16*16/24*24/32*32/48*48/64*64/96*96/128*128/adaptable size; Vector/Lattice |
|
Defog |
Yes |
|
Flip |
Normal/Inverted Flip |
|
Regional Exposure |
Yes |
|
Regional Focus |
Yes |
|
Demist |
Yes |
|
Privacy Mask |
24 regions |
|
Feature |
|
|
Alarm Trigger |
Panorama:Motion Detection Detail:Motion Detection; Panorama:Mask Alarm Detail:Mask Alarm; Disk Full; Disk R/W Error; IP Address Conflict; MAC Address Conflict; FTP Server Exception ; Event Input,Event Output; Network cable disconnected |
|
Linkage Method |
send email; trigger sound; trigger warmlight; trigger recording; trigger capture; notify surveillance center |
|
Video Analytics |
Panorama:Human/Vehicle Classification Detail:N/A; Panorama:Tripwire Detail:N/A; Panorama:Double Tripwire Detail:N/A; Panorama:Perimeter Detail:N/A; Panorama:Object Abandon Detail:N/A; Panorama:Object Lost Detail:N/A; Panorama:Heatmap Detail:N/A; Panorama:Loitering Detail:N/A; Panorama:Running Detail:N/A; Panorama:N/A Detail:N/A; Panorama:People Counting Detail:N/A; Panorama:Crowed Detail:N/A; Panorama:Safety Helmet Detection Detail:N/A; Panorama:On Duty Detection Detail:N/A; Panorama:Video Abnormal Detail:N/A; Panorama:N/A Detail:Audio Abnormal |
|
Early Warning(EW) |
Early Warning(EW) |
|
Auto-Tracking |
Auto-Tracking |
|
Face Mode |
Capture facial images |
|
Network |
|
|
ANR |
ANR |
|
Protocols |
HTTP; HTTPS; TCP/IP; UDP; UPnP; ICMP; IGMP; SNMP v1; DHCP; DNS; DDNS; Easy DDNS; NTP; SMTP; TLS; SSL; 802.1x; QoS; IPv4; IPv6; PPPOE; Unicast; Multicast; ARP; RTP; RTSP; FTP; PING |
|
System Compatibility |
ONVIF Profile S/T/G; CGI |
|
Remote Connection |
≤7 |
|
User/Host |
Up to 32 users. 4 user levels |
|
Client |
Easy7 Smart Client |
|
Moblie Client |
EasyLive Plus |
|
Interface |
|
|
Communication Interface |
2*RJ45 10M/100M/1000M self adaptive Ethernet port |
|
Audio I/O |
1*Input Impedance 1kΩ,2.0~2.4Vp-p; 1*Output Impedance 600Ω |
|
Alarm I/O |
3,Switching; 2,Switching,Voltage≤DC24V,Current≤1A |
|
Reset Button |
Yes |
|
On-board storage |
Built-in Micro SD card slot, up to 512 GB |
|
RS-485 |
RS485 |
|
Electronic Compass |
Yes |
|
GPS/BDS |
Yes |
|
General |
|
|
Web Client Language |
16 languages Simple Chinese/English/Traditional Chinese/Spanish/Italian/ Korean/Turkish/Russian/Thai/ Polish/French/Dutch/Hebraism/Vietnamese/Arabic/Farsi |
|
Operating Temperature |
-40℃～70℃(IR OFF) -40℃～40℃(IR ON) |
|
Operating Humidity |
0～95% |
|
Storage Temperature |
-40℃～70℃ |
|
Storage Humidity |
0～95%(non-condensing) |
|
Power Supply |
AC24V±25%\DC24V±10% |
|
Protection |
Surge protection 4000V; Lightning proof 6000V; IP66 |
|
Material |
Metal |
|
Boundary Dimensions |
φ191mmx344mm(V)x350mm(H) |
|
Package Dimensions |
600(L)*490(W)*290(H)mm |
|
GrossWeight |
11.05 kg |
|
NetWeight |
7.2kg |
