Thermal & Optical Bi-spectrum AI PTZ Camera

Thermal   Sensor Type

Vanadium   Oxide Uncooled Focal Plane Arrays

Thermal   Length

50mm

Resolution

384x288

Piexl   Interval

17μm

Response   Waveband

8μm~14μm

NETD

≤40mK@f/1.0

Thermal   FOV

Horizontal:   7.5°,Vertical: 5.6°

Measurement   Distance
  Based on the reference:
  human (1.8m x 0.5m)
  vehicle (4m x 1.4m)

Detection:   4510m (vehicle),1471m (human)
  Recognition: 1127m (vehicle),368m (human)
  Identification: 564m (vehicle),184m (human)

Fire   Detection Distance
  Based on the reference:
  fire (2m×2m)

3000m

Camera

Image   Sensor

1/1.8"CMOS

Min.   Illumination

Optical:   Color:0.001lux@ (F1.6,AGC ON),B/W:0lux with IR

Shutter   Time

1s~1/100000s

Day&Night

IR-cut filter with auto switch (ICR)

Smart   IR

Yes

WDR

120dB

Lens

Focal   Length

Optical:6mm～264mm

Optical   Zoom

44X

Digital   Zoom

16X

Zoom   Speed

<6s

Aperture   Range

Optical:F1.6~F5.3

Aperture   Type

Optical:Auto(P-Iris)

Field   of View

Optical:61.8°~2.3°(H);36.3°~1.3°(V);69°~2.6°(D)

Focus   Control

Optical:Auto/Semi-auto/Manual

Close   Focus Distance

Optical:100mm~1500mm

DORI   Distance

Optical:   Detect:2620m Observe:1040m Recognize:524m Identify:262m

Pan&Tilt

Pan   Range

360°

Pan   Speed

Manual   Speed:0.1°～200°/s Preset Speed:240°/s

Tilt   Range

-21°~90° (Default -13°~90°)

Tilt   Speed

Manual   Speed:0.1°～120°/s Preset:180°/s

3D   Position

Yes

Preset

500

Cruise

16,up   to 32 presets per cruise

Scan

8

Pattern

8,each   with 600s memory or 1000 orders

Scheduled   Task

Preset,Cruise,Scan,Pattern

North   Point

Yes

Power-off   Memory

Yes

Preset   Freezing

Yes

Illuminator

IR   LEDs

11

IR   Distance

Up   to 300m

Wavelength

850nm

IR   Irradiation Angle

Yes

White   LEDs

2

Whitelight   Distance

30m

Compression   Standard

Video   Compression

S+265/H.265/H.264B/H.264M/H.264H/Motion   JPEG

Video   Bit Rate

32Kbps~16Mbps

Audio   Compression

G.711A/G.711U/ADPCM_D/AAC_LC

Audio   Sampling Rate

8KHz/32KHz/48KHz


Max.   Resolution

Optical:3072×1728@30fps   Thermal:384×288@30fps

Main   Stream

Optical:   PAL:25fps(3072×1728,2560×1440,2304×1296,1920×1080,1280×720) 50fps(2560×1440,2304×1296,1920×1080,1280×720) NTSC:30fps(3072×1728,2560×1440,2304×1296,1920×1080,1280×720) 60fps(2560×1440,2304×1296,1920×1080,1280×720)
  Thermal: PAL:25fps(384×288) NTSC:30fps(384×288)

Sub   Stream

Optical:   PAL:25fps(704×576,704×288,352×288,640×360) NTSC:30fps(704×480,704×240,352×240,640×360)
  Thermal: PAL:25fps(384×288) NTSC:30fps(384×288)

Third   Stream

Optical:   PAL:25fps(1920×1080,1280×720,704×576,704×288,352×288,640×480)   NTSC:30fps(1920×1080,1280×720,704×480,704×240,352×240,640×480)
  Thermal: PAL:25fps(384×288) NTSC:30fps(384×288)

BLC

Yes

HLC

Yes

AGC

Yes

3DNR

Yes

White   Balance

Auto/Semi-Auto/Manual/Sunshine/Nature   Light/Warmlight Lamp/Daylight Lamp/Filament Lamp/Lock White Balance

ROI

Optical:7   Dynamic Areas for Both Main and Sub Stream

EIS

Yes

OSD

5   regions(Each region can have a maximum of 127 characters,up to 5 lines);   16*16/24*24/32*32/48*48/64*64/96*96/128*128/adaptable size

Defog

Yes

Flip

Normal/Inverted   Flip

Regional   Exposure

Yes

Regional   Focus

Optical:Yes

Demist

Yes

Privacy   Mask

24   regions

Feature

General   Alarm

Optical:Motion   Detection Thermal:Motion Detection; Optical:Mask Alarm

Exceptions   Alarm

Disk   Full; Disk R/W Error; IP Address Conflict; MAC Address Conflict; FTP Server   Exception ; Network cable disconnected

Linkage   Method

Send   Email; Trigger Sound; Trigger Warmlight; Trigger Recording; Trigger Capture;   Notify Surveillance Center; Alarm Output

Video   Analytics

Optical:Perimeter;Tripwire;Double   Tripwire;Object Abandon;Object Missing;Heatmap;Loitering;Running;People   Counting;Crowed Detection;Safety Helmet Detection;On Duty Detection;Video   Abnormal;Audio Abnormal;Human/Vehicle Classification
  Thermal:Perimeter;Tripwire;Double Tripwire;Human/Vehicle Classification

Auto   Early Warning(AEW)

Yes

Auto-Tracking

Yes

Face   Mode

Face   Capture

Face   Capture Performance

Detect   up to 32 faces at the same scene; Capture up to 16 faces at the same scene

Network

ANR

Yes

Protocols

HTTP;   HTTPS; TCP/IP; UDP; UPnP; ICMP; IGMP; SNMP v1; DHCP; DNS; DDNS; Easy DDNS;   NTP; SMTP; TLS v1.2; SSL; IPv4; IPv6; PPPoE; Unicast; Multicast; ARP; RTP;   FTP

System   Compatibility

P2P;   ONVIF(Profile S/T/G); SDK; CGI; RTSP

Remote   Connection

≤7

User/Host

Up   to 32 users. 4 user levels

Client

Easy7   VMS

Moblie   Client

EasyLive   Plus

Web

IE10+;   Firefox52+; Edge89+; Safari11+; Chrome57+

Interface

Communication   Interface

2*RJ45   (10/100/1000Base-T)

Audio   I/O

1*Input   Impedance 1kΩ,2.0~2.4Vp-p; 1*Output Impedance 600Ω

Alarm   I/O

8*Switching;   2*Switching,Voltage≤DC24V,Current≤1A

Built-in   Speaker

1,4Ω4W

Reset   Button

Yes

On-board   Storage

Built-in   Micro SD card slot,up to 512 GB

Additional   Interfaces

RS485;   BNC

Wiper

Yes

Electronic   Compass

Yes

GPS/BDS

Yes

General

Web   Client Language

16   languages
  Simple Chinese/English/Traditional Chinese/Spanish/Italian/   Korean/Turkish/Russian/Thai/ Polish/French/Dutch/ Hebraism/Vietnamese/Arabic/Farsi

Operating   Temperature

-40℃~70℃(-40℉~158℉)

Operating   Humidity

≤95%RH

Storage   Temperature

-40℃~70℃(-40℉~158℉)

Storage   Humidity

10%~95%RH(non-condensing)

Power   Supply

AC24V±25%\DC36V±25%

Power   Consumption

48W(IR   OFF) ; 67W(IR ON)

Protection

Surge4000V;   ESD6000V; IP66

Material

Metal

Boundary   Dimensions

308mm(D)x505mm(H)

Package   Dimensions

460(L)460(W)720(H)mm

GrossWeight

21.4Kg

NetWeight

11.85kg
